Brand Name : LTPM CHINA
Model Number : ZP-Series
Certification : CE
Place of Origin : China
MOQ : 1 set
Price : Negotiation
Payment Terms : 30% TT as deposit and 70% before shipping
Supply Ability : 25 sets
Delivery Time : In 35 days after receiving the deposit
Packaging Details : Wooden Case
Production capacity : 40000-85000pcs/h
Max. Diameter of tablet to be produced (mm) : 25
Voltage (v/hz) : 380/50
Max. Thickness of tablet (mm) : 9
Weight : 1950KG
Total power : 7.0kw
Rotary speed of the turret (rpm) : 14-35
Dimensions : 1240*850*1850
1. “ZP SeriesROTARY TABLET PRESS” is a versatile machine in the range of This manual, giving exhaustive information on operation and maintenance of this machine, is intended for the operator as well as maintenance staff, to enable them to obtain long and trouble free service throughout its use. To derive maximum benefits out of this machine, it is expected to adhere the instructions given in this manual.
2. Details of the machine regarding technical specifications, instruction for installation, operation, lubrication,adjustments, special design are elaborated at Lubrication, which is very vital for extended life of the machine, may please be observed as per the instructions given.
3. In case of any doubt or clarification, we WOULD BE PLEASED TO OFFER OUR BEST SERVICES ALL THE TIME.
No. of stations | 31 Stations |
Production Capacity (pc/h) | 111600 |
Turret RPM (Mini. /Max.) | 0-30 |
Max. Pressure (KN) | 100 |
Maximum Dia of Tablet(mm) | 22 |
Maximum Depth of filling(mm) | 15 |
Dia. of upper punch(mm) | 115 |
Dia. of lower punch(mm) | 115 |
Dia. of central die(mm) | 34 |
Motor Power(kw) | 4-7.5 |
Overall Dimensions (mm) | 1240*850*1850 |
Net Weight (kg) | 1950 |
